Q-Power 107 Series Cattle Crush

107 series uk main image

More than just a silent hydraulic cattle crush

Product Code: 1070
Product Features | Product Specifications

Weight: 1173 kg

Dimensions: 1524mm Wide x 2565mm High x 3429mm Long

7 Options Available

Get my Quote from Arrowquip

* Head Scoop Optional

Read Full Video Transcript

Arrowquip's NEW Q-Power 107 Series is more than a silent hydraulic cattle crush. The Q-Power has been reinvented with more quiet points than ever before - even the slam latches have been optimized for calm, quiet cattle handling! With superior fast-response hydraulics and precision engineering, the Q-Power delivers maximum performance so you can do more work in half the time.

This crush is built for durability and performance, with a structural frame that has been reinforced, and now features the same beams as our portable units! For improved performance, the cylinders and connections have been upgraded to provide faster response with the lightest touch of the controls, enabling you to work more cattle in way less time.

Choose a hydraulic cattle crush that gives you more - more power, more flexibility, and more of your time back to get to the things that really matter.

Fill out this form to receive your Q-Power 107 Series Hydraulic Cattle Crush brochure:

Government TB Testing Regulations

As per the Government of UK website’s tuberculosis testing guidelines, your testing and handling facilities must:

Allow safe movement of cattle;
Include a suitable handling system (such as a crush and penning system linked by a secure race);
Make it easy for inspectors to restrain and examine cattle, clip their hair, measure the skin with calipers, and give them injections;
Be in good working order;
Be suitable for the size and breed of cattle that have to be tested; and
Be well-lit so inspectors can read ear tags and carry out the test.
The new swing arm that lets you operate it from both sides is slick. Got the bigger electric motor and it moves fast. Cattle flow through it easy. The access on this crush is top notch. I would never go buy a silencer over this.

- Hans Hennings, Rancher -

Product Reviews | Leave My Review

Product Features

  • A black calf walking inside of a Q-Power 107 Series hydraulic cattle crush

    3E Q-Power Yoke & Tail Gates - Easy Entry & Exit Technology

    The Q-Power Yoke and Tail Gates use natural cattle behaviour to get cattle to move through the crush more easily with a unique barred style. Arrowquip-exclusive 3E Yoke and Tail Gate technology can be seen on all of our squeeze crush models, and is used to obtain Easy Entry and Exit for livestock in the crush. The barred Yoke and Tail Gate allow cattle to see light and open space at the end of the crush, drawing them towards the Yoke Gate with minimal handler intervention and dramatically reducing processing delays.

  • The hydraulic controls for a Q-Power 107 Series hydraulic cattle crush

    Superior Fast Response Hydraulics

    The fast-touch hydraulics provide superior cattle control with improved cylinders and hydraulic connections for faster response times that enable producers to catch even the rowdiest livestock.

    All hydraulic controls are mounted on the wide-range pivoting swing arm that can be operated at any point along both sides of the cattle crush without any adjustments.

    For added power, choose the Stealth Power Pack upgrade that allows you to operate the yoke and tail gates simultaneously to further improve your processing speed.

  • Hydraulic Cattle Squeeze Crush Stealth Power Pack | Arrowquip Cattle Equipment

    Silent Cattle Handling Redefined

    It is a well-known fact that noise is a significant stressor for cattle, and can dramatically increase their anxiety when being handled. The Q-Power 107 Series takes quiet cattle handling to the next level with 107 quiet points throughout the crush for the quietest cattle handling experience possible. Pair the quietest hydraulic crush on the market with the Stealth Power Pack for a virtually silent cattle handling experience across the board.

  • Close up of cattle crush rubber floor by Arrowquip

    Unmatched Hydraulic Cattle Crush Warranty and Customer Service

    The Q-Power 107 Series is backed by an industry-leading 15-Year Warranty on all parts, including the hydraulics. Additional lifetime warranty applies to the rubber floors, rump fingers, and all locking mechanisms.

    Arrowquip employs a team of dedicated Client Care Specialists who are ready and waiting to support customers throughout their journey with Arrowquip. If you ever have a problem with your product, need maintenance information, would like to request warranty parts, misplace your manual, or any other issue, you can reach out to their team of experts for support.

A Hydraulic Cattle Crush Designed for TB Testing

The Q-Power 107 Series hydraulic cattle crush is designed for effective TB testing, offering 324mm of access to the neck. This access area features a fully removable panel that provides better accessibility than any other crush on the market, and can be used to complete SICCT testing with ease. Using the Q-Power 107 Series for your TB testing ensures your livestock with remain at low stress levels, making the tuberculosis testing process easier on you, your livestock, and your testing personnel.

For more information, visit our TB Testing page.

See what Others Have to Say
Want more information?

Contact Arrowquip

Product Specifications

  • 15-Year Hydraulic Cattle Crush Warranty
  • Hydraulics are controlled from the pivoting swing arm: 3E Yoke Gate, 3E Rear Gate, Squeeze, Head Sweep (Optional)
  • Hydraulic squeeze ranges from 750mm fully open to 195mm fully closed
  • Improved wide-range pivoting swing arm has a larger range and allows you to operate the hydraulic controls anywhere along either side of the crush
  • New yoke gate design uses light to draw cattle into the crush
  • Curtain-style yoke gate opens to a full 762mm top to bottom for cattle to exit the crush
  • Poly-coated slam latches eliminate metal clanging
  • Two rows of rump fingers ensure safety no matter the size of the animal
  • Poly-composite rump fingers are engineered to endure high pressure
  • Vet door opens in both directions for a full 180° of manoeuvrability
  • Low-profile latch ensures the vet cage door will not swing to the inside of the crush when slammed shut
  • Swing-out top and bottom access doors can be used individually or together to access the entire animal
  • Side access panels are removable and can be configured in a variety of positions to suit your farms needs
  • 324mm top to bottom needle door access
  • New drop-down needle bar allows for quick injections
  • Rectangular tubing limits cattle bruising
  • Pivot and latch points feature poly bushings for silent operation
  • True virgin rubber flooring dampens sound and provides great traction
  • Rubber floor is backed by a lifetime guarantee
  • Mount brackets enable you to add load bars or secure the crush to concrete

Misplaced your manual? Download another one now

Available Add-Ons / Options

  • hydraulic head sweep on 3e yoke gate

    Hydraulic Head Sweep

    This simple, gentle, and effective option can be connected to the controls on your hydraulic cattle crush to hold the animal's head in place with ease.

  • Yellow cattle head scoop in closed position

    Third-Generation Cattle Head Scoop [Patented]

    The 3rd Generation Q-Catch Head Scoop is stronger, easier to use, and more durable than its predecessor. The cattle head scoop secures the animals neck to hold the head immobile, allowing the farmer safe, up-close access for any procedure necessary. Featuring a patented single handle push-pull operation, the head scoop makes life easier for farmers everywhere to manage their cattle.

    [ More Information on the Third-Generation Cattle Head Scoop [Patented] ]
  • Cattle brisket bar - sheeted

    Brisket Bar

    The brisket bar supports cattle to keep them standing during stressful periods, and prevent them going down in the crush. The new brisket bar comes sheeted to eliminate hoof traps and can be installed with only two bolts.

    [ More Information on the Brisket Bar ]
  • Clipping rail for Arrowquip cattle crushes

    Clipping Rail

    The clipping rail allows handlers to safely open both doors of the crush while keeping cattle contained, and can be adjusted to accommodate cattle of different sizes. This simple and effective option can be installed or removed from the crush with just 4 bolts.

  • Hydraulic Cattle Squeeze Crush Electric Power Pack | Arrowquip Cattle Equipment

    Electric Hydraulic Power Pack

    The Electric Power Pack comes standard with a 3.7kW single phase 4 pole motor, in-line filter, gear pump delivering 28 litres/min. 45 litre tank with filter breather, manifold block with release valve set at 62 bar, and quick release couplings.

  • Hydraulic Cattle Squeeze Crush Gas Power Pack | Arrowquip Cattle Equipment

    Gas Hydraulic Power Pack

    7HP gas motor. Operating pressure of 900PSI, with relief set at 1000PSI. The 10-gallon tank delivers 6.2GPM. Pioneer female ends on the power pack allow the connecting hose on the chute to plug straight in.

  • Hydraulic Cattle Squeeze Crush Stealth Power Pack | Arrowquip Cattle Equipment

    NEW Stealth Upgrade Electric Power Pack

    The NEW Stealth Upgrade Electric Power Pack is a truly silent power source with a 7.5HP electric motor. Operating pressure of 900PSI, with relief set at 1000PSI. The 10-gallon tank delivers 10.9GPM. Pioneer female ends on the power pack allow the connecting hose on the chute to plug straight in.
